LED Ecoplus T8 600 G13 10W (18W) 1200lm 965 EM+AC

Article number: 145863

BAI Ecoplus T8 LED Tube 29x600mm G13 10W (18W) 1200lm 6500K CRI90 Glass EM Retrofit + AC 230V-240V 280° Temp. -20°C +40°C Alt T26 TLD Lumilux LED-lamp

The Ecoplus daylight lamps are LED lamps that display the full spectrum of natural daylight almost identically. Biologically stimulating effect, the best contrast perception, absolutely true-to-life color rendering due to color temperature in the optimal daylight range of 6500K, optimal color rendering properties Ra90 - CRI90 (= 1A). Installation: Disconnecting magnetic ballast is optional, not necessary. Not suitable for series connection and for for electronic ballast. Replace the fluorescent starter with the LED starter (supplied). Ambient temperature range: -20°C to +50°C.

Please read the manual before use.

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

Click here for Eprel specifications

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED Ecoplus T8 600 G13 10W (18W) 1200lm 965 EM+AC
Brand
Bailey
Productseries
Ecoplus LED tube
Producttype
T8 CRI90
GTIN
8714681458631
Manufacturer articlenumber
145863

ETIM specifications

Socket
G13
Luminous flux [lm]
1200 - 1200
Nominal voltage [V]
220 - 240
Lamp power [W]
10 - 10
Colour temperature [K]
6500 - 6500
Diameter [mm]
29
Length [mm]
600
Dimmable
No
Lamp shape
Tube, double-ended
Beam angle [°]
280 - 280
Colour
White
Type of glass/cover
Opal
Lamp designation
T8
Colour rendering index CRI
90-100
Voltage type
AC
Filament lamp
No
Rated luminous flux according to IEC 62612 [lm]
1200
Power factor
0.9
Lamp efficacy [lm/W]
120
Nominal current [mA]
48 - 48
Colour of light according to EN 12464-1
Daylight white > 5300 K
Housing colour
White
Average nominal lifetime [h]
30000
Degree of protection (IP)
IP20
Energy efficiency class
E
Colour consistency (McAdam ellipse)
SDCM6
Min. number of switching cycles
15000
Weighted energy consumption in 1000 hours [kWh]
10
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
RG1
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
Yes
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
Yes
Energy efficiency class according to EU regulation 2019/2015
E
With twilight switch
No
Material of light bulb
Glass
Downloads
Manual
IM_LEDT8EMAC-01.pdf
Cross-reference list
Bailey_Cross_Reference_LED_T8_Tubes.pdf
