LED PL 2G11 2S TC-L 15W (36W) 840 FR EM+AC

Article number: 80100040747

BAI LED PL 2G11 TC-L 15W (36W) 4000K 1500lm Double-sided light Frosted 100V-240V 240° 44x422mm LED-lamp Alt PLL Dulux L

The LED PL 2G11 (4-pin) TC-L lamps with double-sided light are replacements for the commonly used compact fluorescent lamps without integrated ballast. PL stands for PubLic as these lamps are mainly used in public areas (indoor and outdoor) and as general lighting in shops, offices and hotels. Installation: Conventional ballast: Always remove the starter. Decoupling magnetic ballast is optional, not necessary. Electronic Ballast: Disconnect ballast before use. Always read the manual carefully before installation. Ambient temperature range: -20°C to +40°C.

Please read the manual before use.

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED PL 2G11 2S TC-L 15W (36W) 840 FR EM+AC
Brand
Bailey
Productseries
LED PL
Producttype
2G11 4P
GTIN
8714681407479
Manufacturer articlenumber
80100040747

ETIM specifications

Socket
2G11
Luminous flux [lm]
1500 - 1500
Nominal voltage [V]
100 - 240
Lamp power [W]
15 - 15
Colour temperature [K]
4000 - 4000
Diameter [mm]
44
Length [mm]
422
Dimmable
No
Lamp shape
Tube, single-ended
Beam angle [°]
240 - 240
Colour
White
Type of glass/cover
Frosted
Lamp designation
Other
Colour rendering index CRI
80-89
Voltage type
AC
Filament lamp
No
Rated luminous flux according to IEC 62612 [lm]
1500
Power factor
0.9
Lamp efficacy [lm/W]
100
Nominal current [mA]
200 - 200
Colour of light according to EN 12464-1
Neutral white 3300-5300 K
Housing colour
White
Average nominal lifetime [h]
20000
Degree of protection (IP)
IP20
Energy Efficiency Index (EEI)
0.14
Energy efficiency class
No
Colour consistency (McAdam ellipse)
Other
Min. number of switching cycles
15000
Weighted energy consumption in 1000 hours [kWh]
15
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
Other
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
Yes
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
Yes
Energy efficiency class according to EU regulation 2019/2015
No
With twilight switch
No
Material of light bulb
Plastic
