LED PL Glass TC-TEL GX24q 4P 6W (18W) 800lm 830 AC

Article number: 146754

BAI LED PL Glass GX24q 4-pins TC-TEL 6W (18W) 3000K Frosted 800lm 230V-240V 360° 49x120mm Temp. -20°C +40°C LED-lamp Alt PLT Dulux T/E

The LED PL Glass GX24 (4-pin) TC-TEL lamps are replacements for the often used compact fluorescent lamps without integrated ballast. PL stands for PubLic as these lamps are mainly used in public spaces, corridors, offices and as orientation lighting. This PL LED series has the same shape and size as its fluorescent predecessors. In addition, just like their predecessor, they are made of glass, which ensures the same uniform light image. They are therefore a 1-on-1 sustainable replacements. Connect directly to mains voltage (AC). Not for use with Electronic Ballast (HF/ECG), disconnect ballast before use! Always read the manual carefully before installation.

Please read the manual before use. Available ± December 2025

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

Click here for Eprel specifications

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED PL Glass TC-TEL GX24q 4P 6W (18W) 800lm 830 AC
Brand
Bailey
Productseries
LED PL Glass
Producttype
GX24q 4P AC
GTIN
8714681467541
Manufacturer articlenumber
146754

ETIM specifications

Socket
Other
Luminous flux [lm]
800 - 800
Nominal voltage [V]
220 - 240
Lamp power [W]
6 - 6
Colour temperature [K]
3000 - 3000
Diameter [mm]
49
Length [mm]
120
Dimmable
No
Lamp shape
Tube, single-ended
Beam angle [°]
360 - 360
Colour
White
Type of glass/cover
Opal
Lamp designation
Other
Colour rendering index CRI
80-89
Voltage type
AC
Filament lamp
No
Rated luminous flux according to IEC 62612 [lm]
800
Power factor
0.5
Lamp efficacy [lm/W]
133
Nominal current [mA]
48 - 48
Colour of light according to EN 12464-1
Warm white < 3300 K
Housing colour
White
Average nominal lifetime [h]
30000
Degree of protection (IP)
IP20
Colour consistency (McAdam ellipse)
SDCM5
Min. number of switching cycles
15000
Weighted energy consumption in 1000 hours [kWh]
6
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
RG0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
Yes
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
Yes
Energy efficiency class according to EU regulation 2019/2015
E
With twilight switch
No
Material of light bulb
Glass
Downloads
Manual
IM_LED_PL-Glass_GX24q-A502.pdf

Alternative articles
DULUX T/E LED GX24q-2 HF & AC 7W (18W) 830

146345
