LED HID G12 DIM 14W (35W) 1850lm 840 AC 230V

Article number: 146246

BAI LED HID G12 14W 4000K 1850lm Dimmable Clear 230V-240V 300° 30x99mm Alt. 35W CMH-T CDM-T LED-lamp REMOVE FIXTURE COVER

The compact LED G12 lamps are ideal as a replacement for ceramic metal halide lamps. These lamps are often used in shops, shop windows and museums. Installation: disconnect ballast, capacitor and igniter before use. Only suitable for temperatures up to 40°C inside the fixture. The LED light source can quickly malfunction due to overheating. Therefore not suitable for use in tight fixtures or fixtures where the reflector is close to the LED. Recommended to remove glass or cover from the fixture.

Please read the manual before use.

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

Click here for Eprel specifications

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED HID G12 DIM 14W (35W) 1850lm 840 AC 230V
Brand
Bailey
Productseries
LED HID
Producttype
G12 HO
GTIN
8714681462461
Manufacturer articlenumber
146246

ETIM specifications

Socket
G12
Luminous flux [lm]
1850 - 1850
Nominal voltage [V]
220 - 240
Lamp power [W]
14 - 14
Colour temperature [K]
4000 - 4000
Diameter [mm]
30
Length [mm]
99
Dimmable
Yes
Lamp shape
Tube, single-ended
Beam angle [°]
300 - 300
Colour
White
Type of glass/cover
Clear
Lamp designation
Other
Colour rendering index CRI
80-89
Voltage type
AC
Filament lamp
No
Rated luminous flux according to IEC 62612 [lm]
1850
Power factor
0.7
Lamp efficacy [lm/W]
137
Nominal current [mA]
60 - 60
Colour of light according to EN 12464-1
Neutral white 3300-5300 K
Housing colour
White
Average nominal lifetime [h]
15000
Degree of protection (IP)
IP20
Energy efficiency class
E
Colour consistency (McAdam ellipse)
SDCM6
Min. number of switching cycles
25000
Weighted energy consumption in 1000 hours [kWh]
14
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
RG0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
No
Dimming phase cut-off (trailing edge)
Yes
Dimming phase cut-on (leading edge)
Yes
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
No
Energy efficiency class according to EU regulation 2019/2015
E
With twilight switch
No
Material of light bulb
Plastic
Downloads
Manual
IM_LEDG12-01.pdf

Complementary articles
Lampholder G12 4A 750V T300°C 300mm

92600036349
