LED Spot AR111 GU10 DIM 9W (75W) 620lm 927 40° Bridge
Article number: 145706
BAI LED Spot AR111 GU10 9W (75W) 620lm Dimmable 2700K CRI90 40° Anti-Glare bridge 72x111mm LED-Lamp
This AR111 spot, with it's Anti-Glare bridge, replaces almost all halogen versions with a GU10 lamp base and is available in 24 and 40 degrees. Ambient temperature range -20° C to 40°C.
Data not available (yet). Please contact our sales department for more information.
General ETIM properties
ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED Spot AR111 GU10 DIM 9W (75W) 620lm 927 40° Bridge
Brand
Bailey
Productseries
BaiSpot LED MV
Producttype
AR111 Bridge
GTIN
8714681457061
Manufacturer articlenumber
145706
ETIM specifications
Socket
GU10
Luminous flux [lm]
620 - 620
Nominal voltage [V]
220 - 240
Lamp power [W]
9 - 9
Colour temperature [K]
2700 - 2700
Diameter [mm]
111
Length [mm]
72
Dimmable
Yes
Lamp shape
Reflector
Beam angle [°]
40 - 40
Colour
White
Type of glass/cover
None
Lamp designation
AR111
Colour rendering index CRI
90-100
Voltage type
AC
Filament lamp
No
Luminous intensity [cd]
1480
Rated luminous flux according to IEC 62612 [lm]
620
Power factor
0.9
Lamp efficacy [lm/W]
68
Nominal current [mA]
40 - 40
Colour of light according to EN 12464-1
Warm white < 3300 K
Housing colour
Black
Average nominal lifetime [h]
15000
Degree of protection (IP)
IP20
Energy efficiency class
G
Colour consistency (McAdam ellipse)
SDCM6
Min. number of switching cycles
30000
Weighted energy consumption in 1000 hours [kWh]
9
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
RG1
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
No
Dimming phase cut-off (trailing edge)
Yes
Dimming phase cut-on (leading edge)
Yes
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
No
Energy efficiency class according to EU regulation 2019/2015
G
With twilight switch
No
Dimmer compatibility list
