LED B22d T27X58 10V-30V 4W (42W) 500lm 830 Clear

Article number: 143326

BAI LED Compact Tube 27x58mm B22d 10V-30V AC/DC 4W 3000K 500lm (42W) Clear 300° Laagvolt 12V 24V 28V LED-lamp

The Led compact series consists of lamps that, due to their compact design and high luminous flux, are ideal as replacements for conventional lamps. Only suitable for temperatures up to 40°C inside the fixture. The LED light source can quickly malfunction due to overheating. Therefore not suitable for use in tight fixtures or fixtures where the reflector is close to the LED. Recommended to remove glass or cover from the fixture. Ambient temperature: -20°C to +40°C.

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

Click here for Eprel specifications

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED B22d T27X58 10V-30V 4W (42W) 500lm 830 Clear
Brand
Bailey
Productseries
LED Special
Producttype
Tube B22d
GTIN
8714681433263
Manufacturer articlenumber
143326

ETIM specifications

Socket
B22d
Luminous flux [lm]
500 - 500
Nominal voltage [V]
10 - 30
Lamp power [W]
4 - 4
Colour temperature [K]
3000 - 3000
Diameter [mm]
27
Length [mm]
58
Dimmable
No
Lamp shape
Tube, single-ended
Beam angle [°]
300 - 300
Colour
White
Type of glass/cover
Clear
Lamp designation
Other
Colour rendering index CRI
80-89
Voltage type
AC/DC
Filament lamp
No
Rated luminous flux according to IEC 62612 [lm]
500
Power factor
0.7
Lamp efficacy [lm/W]
125
Nominal current [mA]
200 - 450
Colour of light according to EN 12464-1
Warm white < 3300 K
Housing colour
White
Average nominal lifetime [h]
15000
Degree of protection (IP)
IP20
Energy Efficiency Index (EEI)
90
Energy efficiency class
E
Colour consistency (McAdam ellipse)
SDCM6
Min. number of switching cycles
12500
Weighted energy consumption in 1000 hours [kWh]
4
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
RG1
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
No
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
Yes
Energy efficiency class according to EU regulation 2019/2015
E
With twilight switch
No
Material of light bulb
Plastic
