LED Spot MR11 Glass GU4 12V 1.8W (20W) 180lm 840 38° Open

Article number: 142547

BAI BaiSpot LED LV MR11 GU4 12V AC/DC 1.8W 4000K 38° 180lm (20W) Glass Reflector 35x35mm LED-lamp

The so-called LED spots from the BaiSpot series are characterized by a much longer lifespan and significantly less energy consumption than their halogen predecessors. Due to the compact design, they are easily interchangeable. Spots are mainly used to provide directed light from the ceiling or wall. This glass version literally and figuratively has an extra beautiful appearance because the part through which the light shines is made entirely of glass. Ambient temperature range: -20°C to +35°C

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

Click here for Eprel specifications

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED Spot MR11 Glass GU4 12V 1.8W (20W) 180lm 840 38° Open
Brand
Bailey
Productseries
BaiSpot LED LV
Producttype
MR11 Glass
GTIN
8714681425473
Manufacturer articlenumber
142547

ETIM specifications

Socket
GU4
Luminous flux [lm]
180 - 180
Nominal voltage [V]
12 - 12
Lamp power [W]
1.8 - 1.8
Colour temperature [K]
4000 - 4000
Diameter [mm]
35
Length [mm]
35
Dimmable
No
Lamp shape
Reflector
Beam angle [°]
38 - 38
Colour
White
Type of glass/cover
None
Lamp designation
MR11
Colour rendering index CRI
80-89
Voltage type
AC/DC
Filament lamp
No
Luminous intensity [cd]
155
Rated luminous flux according to IEC 62612 [lm]
180
Power factor
0.7
Lamp efficacy [lm/W]
100
Nominal current [mA]
190 - 190
Colour of light according to EN 12464-1
Neutral white 3300-5300 K
Housing colour
Other
Average nominal lifetime [h]
15000
Degree of protection (IP)
IP20
Energy Efficiency Index (EEI)
0.11
Energy efficiency class
No
Colour consistency (McAdam ellipse)
Other
Min. number of switching cycles
30000
Weighted energy consumption in 1000 hours [kWh]
2
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
Other
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
No
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
Yes
Energy efficiency class according to EU regulation 2019/2015
No
With twilight switch
No
Material of light bulb
Glass
Downloads

Predecessor
BaiSpot LED MR11 GU4 12V 1.8W/840 38° Glass

80100041291
